NETSOLAR UL1741 10KW Solar Off Grid Inverter 110/220Vac Low Frequency DC 48V AC Input 240V AC Output 120V/240V Split Phase Pure Sine Wave Power Converter with 2x60A MPPT Charger Controller 10000W

Price: [price_with_discount]
(as of [price_update_date] – Details)

[ad_1]

Product Description

GS Series Inverter

GS inverter is low frequency pure sine wave Dc 48V to AC 220V all in one inverter. Electrically integrated solar inverter consists of a 8KW 10KW and 12KW DC 48V to 120/240-volt AC split phase pure sine wave inverter with two 60A MPPT solar charge controller, and AC charger to DC battery charger and an automatic transfer switch ideal for your off-grid solar system.With reliable intelligent design, GS series solar inverter can be available to complicated appliances.Not only used for common appliances such as TV computer, lights, fans.but also suitable for inductive loadings such as refrigerators, airconditioners, motors, pumps compressors and laser printers.Convertible to electrical energy from wind and solar.

Important Safety Warning

Before using the unit, read all instructions and cautionary markings on: (1) The unit (2) the batteries (3) all appropriate sections of the manual.

This Inverter Support 2x60A MPPT Solar Charger ControllerThe maximum solar charging current :2x60A=120AThe maximum charging current : 200A (2x60A MPPT+80A AC Charger =200A)Rated charge current:60ARated Battery voltage:48VDCInput voltage range:50-145VdcMax. PV open circuit array voltage:150VdcMax. recommended input power (W) :3500W

GS Series hybrid Inverter is designed to serve as a backup power supply for AC loads.

The input power of GS Series hybrid Inverter comes from PV system and AC grid which not only supply power to AC loads but also charge the battery bank when the power from AC grid or AC generator is present (also known as Line Mode).In the event of AC grid (or AC generator) outage, the AC loads can be alternatively powered by PV system (if the illumination is sufficient) and battery bank.GS inverter realizes the use of solar energy and wind energy to convert into electric energy, which can save more electricity bills and allow you to use electricity freely.

10KW split phase pure sine inverter charger DC 48V AC 240V input AC output 120V/240V

Automatic Generator Starting (AGS)when low battery voltage or no utility.Support 2x60A MPPT Solar Charger Controller.5 stages adjustable AC charging current. AC charging also can be closed.8 kinds of battery voltage selection ( lithium LiFePO4, gel, AGM and lead Acid batteries）.5 stages adjustable AC charging current. AC charging also can be closed.Powerful Charge Rate Up to 200Amp, Selectable From 0%-100%.Built-in transfer switch and battery charge, backup or off grid power solutions.AC/Battery Priority Mode, Designates the Inverter-Preferred UPS Configuration.4-step Intelligent Battery Charging, PFC for Charger.Smart fan adjustment(The fan automatically adjusts the wind speed according to the ambient temperature).Remote control line can be connected (without accessories, optional accessories if needed).

Earthing(ABYC standard)

Inverter mode: the neutral and the earth joinedLine mode: the neutral and the earth separatedUse a Relay to realize the function.

LCD OPERATION

LCD Panel and Configuration Switch

Smart fan Adjustment

The fan automatically adjusts the wind speed according to the ambient temperature

Low Frequency Split Phase

48 VDC input, 240V input VAC to 120/240V AC split phase output This low frequency unit is a combination of an DC to AC power inverter, battery charger and AC auto-transfer switch into one complete system

Inverter Output Specifications

Continuous Output Power: 10000 WattsSurge Rating: 30000 WattsOutput Wave Form: Pure Sine WaveOutput Voltage: 120/240VacNominal Efficiency: 90% (Peak)Line Mode Efficiency: >99%Output Frequency: 50Hz / 60Hz ± 0.3HzTypical Transfer Time: 10ms

Inverter Input Specifications

Nominal DC Input Voltage: 48.0VdcLow Battery Alarm: 42.0Vdc-44.0VdcLow battery Trip: 40.0Vdc-42.0VdcHigh Voltage Shut-down: 64.0VdcLow battery Shut-down Recovery:44.0 ± 0.8VdcHigh battery Shut-down Recovery:62.0 ± 0.8VdcIdle Consumption: 230 WattsNominal Input Frequency:50Hz / 60Hz (Auto detection)

Charger Specifications

Output Voltage: Depends on battery typeBattery Initial Voltage for Start Up: 40-62.8V

Nominal Charge Current:

12VDC model: Max 90A24VDC model: Max 70A48VDC model: Max 50A

Over Charge Protection:

Bat. V ≥15.5Vdc, Fault, Buzzer alarm for 12VdcBat. V ≥31.0Vdc, Fault, Buzzer alarm for 24VdcBat. V ≥61.0Vdc, Fault, Buzzer alarm for 48Vdc

🌞💡【ETL certification to UL 1741 standards 】We strive to reliable, cost-effective clean energy products and power quality life.The GS Series Inverter by an ETL certification to UL 1741 standards ,This will be your best choice.You can use it with more peace of mind, let it help you save more on your electricity bills, and at the same time keep you ready for the next power outage.
🌞💡【Built in Mppt solar controller】Smart Remote Control, Automatic Generator Starting (AGS)when low battery voltage or no utility, Support 2x60A MPPT Solar Charger Controller,which can accept two strings of 60A PV (Max 3500w) input from two solar arrays or parallel to accept 120A (Max 2X3500w) input from one big PV array.Maximum charging current 200A, Smart fan adjustment(The fan automatically adjusts the wind speed according to the ambient temperature).
🌞💡【Working Mode】Three modes to choose from ac priority,DC priority, Intelligent mode.The charging current can be set through the LCD screen.With reliable intelligent design, GS series solar inverter can be available to complicated appliances. Not only used for common appliances such as TV computer, lights, fans.but also suitable for inductive loadings such as refrigerators, airconditioners, motors, washing machine,pumps compressors and laser printers.
🌞💡【Low Frequency Inverter】 Built-in pure copper low frequency transformer, multi-protection against overload, short circuit, over-temperature, under & over voltage. the transformer handles higher power spikes with longer duration when it comes to driving inductive loads such as electric motor, pump, compressor, air conditioners.AC output is synchronized in phase and in frequency with the AC input source to protect the inverter and load for seamless transfer.
